Alpha Clean Air Technology Co.,Ltd

Hepa Filter Plexiglass Industrial Clean Room For Yellow Backlight Workshop

Product Details:
Place of Origin: china
Brand Name: alphaclean
Certification: ce
Model Number: customized
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Polywood packing
Delivery Time: 10 days
Payment Terms: L/C, T/T, Western Union
  • Detail Information
  • Product Description

Detail Information

Product Name: Simple Clean Room With Hepa Filter Material: Alluminum Alloy
Warranty: 1 Year Clean Level: ISO5 - 8
FFU Nos.: 100% Covering Wall Material: Plexiglass,acrylic And Pvc
Type: Class 100 -10000 Clean Room Wall: Soft Anti Static PVC Curtain Etc.
Light: Yellow Fluorescent Tube
High Light:

Plexiglass Industrial Clean Room

,

ISO7 Industrial Clean Room

,

Hepa Fan Filter Clean Room Modular

Product Description

Hepa Filter Plexiglass Industrial Clean Room For Yellow Backlight Workshop



Simple Equipped Clean Room With Hepa Fan Filter Uint For Yellow Backlight Workshop



simple clean room is also a kind convenient and fast simple clean room. The clean hood can be designed in conjunction with the general clean room to achieve different cleanliness level areas.



Because of its easy-to-use, high flexibility, short construction period, and mobility, it is widely used in general clean areas to build more levels of clean workshops, which can effectively reduce costs.



The airflow in a modular cleanroom is a very important factor in the overall performance of the cleanroom. Most cleanrooms have an average air velocity of between 0.25-0.5 m/s. This is a relatively low air velocity, and therefore has the potential to be interrupted or disturbed by people and/or machinery within the cleanroom. On the other hand, raising the air speed too high will increase operational costs. When deciding upon the air speed to set within a cleanroom, an enterprise must first confirm that the selected air speed will be able to maintain an environment that meets cleanliness standards. However, the air speed required to meet these requirements should not be exceeded by too much, otherwise you will incur unnecessary costs.



Features:

1. Frame: stainless steel square tube, industrial aluminum alloy square tube, stable, beautiful, no rust, no dust;

2. The clean roof cover is made of 4 cm thick aluminum-plastic composite panels

3. Special purification lamps for clean rooms are used inside.

4. The fan filter unit FFU: adopts centrifugal fan, 1. It has the characteristics of long life, low noise, maintenance-free, low vibration, stable performance, etc. The quality of the fan is reliable, the working life is 100,000 hours or more, and the noise is 50 decibels.



TYPE SOFTWALL CLEAN BOOTH HARDWALL CLEAN BOOTH
Wall Material Anti-static soft PVC wall curtain 106~109Ω Anti-static acrylic 106~109Ω
Cleanliness From Class 100 to Class 10,000
Frame Material Coated steel, anodized aluminum, Stainless Steel
FFU 2'X4' Galvalume in standard size ,110/220v AC 50/60 hz
HEPA Filter H14 Hepa filter 99.997% 0.3micro
Lighting Available in LED and T5
Air condition

For your requirement,

Available in constant temperature air conditioner

/constant temperature and humidity conditioner



CLEANLINESS CLASS LEVEL



ISO Class Fed 208 Controls HEPA filter coverage as % of ceiling Air velocity at table level in FPM Air changes rate per hour
1 - Stringent 100
2 - Stringent 100 70 - 130 > 750
3 1 Stringent 100 70 - 130 > 750
4 10 Stringent 100 70 – 110 500 - 600
5 100 Stringent 100 70 - 90 150 - 400
6 1,000 Intermediate 33-40 25 - 40 60 - 100
7 10,000 Intermediate 10-15 10 - 15 25 - 40
8 100,000 Less stringent 05-10 3 - 5 10 - 15
