Alpha Clean Air Technology Co.,Ltd

Customized Sterile Cleanrooms For Food And Beverage Packaging

Product Details:
Place of Origin: china
Brand Name: alphaclean
Certification: ce
Model Number: ISO clean room
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Polywood packing
Delivery Time: 20 days
Payment Terms: L/C, T/T, Western Union
  • Detail Information
  • Product Description

Detail Information

Clean Room Class: ISO 5 - 8 Cooling/heating: Auto Change (heat Option)
Capacity Range: 7.5 Ton - 30 Ton Scope: Struture , HVAC , Electricity / Monitoring
Period: 1 - 4 Months Service: Field Installation , Commissioning And Training,engineer Are Able To Service Machinery Overseas
Document: Verification And Certification Usage: Air Purification System
High Light:

Customized Sterile Cleanrooms

,

Food Packaging Customized Sterile Cleanrooms

,

Beverage Packaging ISO Clean Rooms

Product Description

Customized Sterile Cleanrooms For Food And Beverage Packaging



General Class Level
Air exchange times
Relative Static Pressure

 New Air Percentage

Class 1000
50-60
>10Pa
10-30%
Class 10000
15-25
>10Pa
Class 100000
10-15
>10Pa



Food packaging workshop guidelines:

1. The air supply in the food packaging clean room is sufficient to dilute or eliminate the pollution generated indoors.

2. The air in the clean room flows from the clean area to the low cleanliness area. The flow of contaminated air is minimal, and the air flow direction at the door and in the indoor building is correct.

3. air supply will not significantly increase indoor pollution.

4. indoor air movement state can ensure that there is no high concentration area in the chamber.



Food and pharmaceutical packaging workshop testing standards



1. Air supply volume and exhaust air volume:

    If it is a turbulent clean room, measure the air supply volume and exhaust air volume. If it is a one-way flow clean room, measure the air flow speed.

2. Airflow control between each zones:

    In order to prove that the direction of airflow movement between the various areas of the purification plant is correct, that is testing the flow from the high clean area to low cleanliness area

    1) The pressure difference between each zone is correct

    2) The airflow in the opening at the door or at the wall, floor, etc. is in the correct direction, that is, from the clean area to the low cleanliness area.

3. Filter leak detection:

The high-efficiency filter and its frame are inspected to ensure that suspended contaminants do not pass through.

    1) Damaged filter

    2) The gap between the filter and its outer frame

    3) Invaded from other parts of the filter unit.

4. Isolation leak detection:

    This test is to prove that suspended pollutants do not penetrate the clean room through building materials.

5. clean room indoor airflow control:

    The type of airflow control test depends on the airflow mode - whether it is turbulent or one-way flow. If the clean room airflow is turbulent, it must be verified that there is no insufficient airflow area in the clean room. In the case of a one-way flow clean room, it must be verified that the wind speed and direction of the entire room meet the design requirements.

6. Suspended particle concentration and microbial concentration:

If these above tests meet the requirements, the particle concentration and microbial concentration are finally measured if needed to verify that it meets the technical requirements for clean room design.







Advantage of ISO Clean Room

1. Easy to disassemble and install according to drawings

  • Customer can customized size and DIY the cleanroom area according to their space requirements
  • The room area can be enlarged at any time, only increase a few GMP panels or doors.
  • Clean room is movable, low cost and low time-consuming.

The construction scheme of modular clean room has many advantages. The accessories of modular system have been verified by a large number of practical use in the experiment of controlling the manufacturing environment. The assembly of clean room with modular system can greatly reduce the design, construction, engineering time and engineering cost of clean room. Modular clean room can usually improve the efficiency by 20 ~ 40% compared with the traditional standardized clean room system. If the clean room needs to be relocated or reconfigured and transformed after completion, the use of modular system is also very conducive to future transformation and clean room migration.

Customized Sterile Cleanrooms For Food And Beverage Packaging 0Customized Sterile Cleanrooms For Food And Beverage Packaging 1
